MTV VARIO PROFI
Kosiarki pielęgnacyjne
With its robust design, the finishing mower MTV VARIO PROFI is suitable for demanding working conditions. It is used for quick and efficient mulching of grass material in orchards, vineyards, parks, pastures, airports, golf courses and other green areas.
It is primarily designed for mulching grassland in permanent crops with different interrow widths, as it allows variable width adjustment during operation, while the low housing allows use under tree canopies. The free-swinging blades on the rotor move away upon impact with an obstacle.
The housing is made of high-strength and wear-resistant sheet metal. In addition to the standard hydraulic offset, the floating linkage ensures good adaptation to uneven surfaces. The flail mower allows for adjustment of the ejection of the mulching material to the middle or to the side, with the possibility of upgrading it with herbicide equipment.
125-290 cm
40-75 KM
2-3 szt.
495-750 kg
Tehnične skice
DANE TECHNICZNE
|
MTV 2 125/160
|
MTV 2 145/195
|
MTV 3 190/260
|
MTV 3 215/290
|
|
|---|---|---|---|---|
|
Szerokość robocza (cm)
|
125/160
|
145/195
|
190/260
|
215/290
|
|
Przesunięcie maszyny (cm)
|
34
|
50
|
71
|
78
|
|
Liczba wirników (szt.)
|
2
|
2
|
3
|
3
|
|
Liczba noży (szt.)
|
2x2
|
2x2
|
3x4
|
3x4
|
|
Moc ciągnika (kW)
|
29-51
|
29-51
|
37-55
|
37-55
|
|
Moc ciągnika (KM)
|
40-70
|
40-70
|
50-75
|
50-75
|
|
Waga maszyny (kg)
|
495
|
559
|
666
|
750
|
DANE TECHNICZNE
MTV 2 125/160
125/160
Szerokość robocza (cm)
2
Liczba wirników (szt.)
40-70
Moc ciągnika (KM)
495
Waga maszyny (kg)
Przesunięcie maszyny (cm)
34
Liczba noży (szt.)
2x2
Moc ciągnika (kW)
29-51
DANE TECHNICZNE
MTV 2 145/195
145/195
Szerokość robocza (cm)
2
Liczba wirników (szt.)
40-70
Moc ciągnika (KM)
559
Waga maszyny (kg)
Przesunięcie maszyny (cm)
50
Liczba noży (szt.)
2x2
Moc ciągnika (kW)
29-51
DANE TECHNICZNE
MTV 3 190/260
190/260
Szerokość robocza (cm)
3
Liczba wirników (szt.)
50-75
Moc ciągnika (KM)
666
Waga maszyny (kg)
Przesunięcie maszyny (cm)
71
Liczba noży (szt.)
3x4
Moc ciągnika (kW)
37-55
DANE TECHNICZNE
MTV 3 215/290
215/290
Szerokość robocza (cm)
3
Liczba wirników (szt.)
50-75
Moc ciągnika (KM)
750
Waga maszyny (kg)
Przesunięcie maszyny (cm)
78
Liczba noży (szt.)
3x4
Moc ciągnika (kW)
37-55
SPRZĘT
Robustna konstrukcija, vsestranska funkcionalnost in dolga življenjska doba.
Standardna oprema1 test
- Hydraulically adjustable variable working width
- Rear linkage
- Low housing on both sides
- Free-swinging blades on the rotor
- Adjustable ejection of the mulched material
- Adjustable sweeper arm length
ADVANTAGES
The machine features specific advantages designed for optimal use
Variable Working Width
The variable working width allows adjustment of the working area according to specific terrain conditions.
Free-Swinging Blades
The free-swinging blades on the rotor move away upon impact with an obstacle.
Low Housing
The low housing on both sides allows for use under tree canopies.
Robust Housing
A robust housing made of high-strength and wear-resistant sheet metal.
Impact Protection
The flexible elastic clutch between the rotor and the drive protects the gearbox from impacts.
Ejection Adjustment
The possibility of adjustment of the ejection of the mulching material to the middle or to the side.
Floating Surface Adjustment
The flail mower features floating adjustment to adapt to uneven surfaces, ensuring optimal performance.
